Auto Steering Motor 50W

Rated Voltage: DC 12V/24V
Power Supply Range: DC 9-36V
Rated Power: 50W
Rated Current: 10A
Rated Speed: 100RPM
The control mode is RS232/CAN.
The servo adopts an integrated design, which is simple to install and easy to maintain.

Contact Now E-Mail Telephone WhatsApp

Product Details

Product Description:

The Unmanned Driving Auto Steering Motor adopts servo design, with high control accuracy, which can reach 0.1 degree. It is widely applied in unmanned agricultural machinery, road administration engineering vehicles, trucks, mine cars, scenic area tour vehicles, agricultural sowing operations (corn and soybeans), etc.

Product Information:

Model	KY170DD01005-08G
Rated Voltage	DC 12V/24V
Power Supply Range	DC 9-36V
Rated Power	50W
Rated Current	10A
Rated Speed	100RPM
Instantaneous Max.Current	20A
Working Mode	Speed Mode, Position Mode
Under voltage protection	7V（Can set）
Over voltage protection	32V（Can set）
Control Method	RS232/CAN
Feedback Part	Incremental encoder
Operating Temp.	-25-+55℃
Storage Temp.	-35-+65℃
Protection Grade	IP55
Cooling Method	Natural Cooling
Weight	≤5kg

Product drawing:

Certificates:

Application Areas:

Package&Transportation:

Why Choose Us:

We will continue to increase investment in research and development and be committed to the innovation and application of cutting-edge technologies.
Implement full-process quality control from raw materials to finished products to ensure stable and reliable performance and consistent quality.
A complete quality management system has been established and ISO9001 certification has been obtained.
Build a comprehensive service system and respond quickly to customer demands.
